An Attendee Tests the New HTC One During a Launch Event in New York
An attendee tests the new HTC One during a launch event in New York, February 19, 2013.Reuters

2013 flagship smartphone HTC One M7 (GSM) owners are still waiting for the official Android Lollipop OS update. If you are running out of patience and want to experience the new v5.0 OS, well American custom mobile software developers team Cyanogen has answered your prayers.

They have released the new CyanogenMod CM12 series Android 5.0.2 Lollipop update with numerous customisation options (more than the official Google update).

This new CM12 milestone software is a nightly version of AOSP (Android Open Source Project) 5.0.2 Lollipop, but we remind our readers that this nightly version is unstable and has some un-tested bugs in it.

Some of features that are missing in the nightly version are:

  1. Theme Engine
  2. Quick Settings reorganisation and customisation
  3. Quick Settings Ribbon mode
  4. Navigation bar reorganisation and customisation
  5. Sound panel customisation
  6. Lock-screen quick unlock

Good news is that Cyanogen has confirmed that they have completed 85% of development of the stable firmware and would roll it out soon. Until then users can upgrade their device with the nightly update.

Prerequisites (Things to remember before installing the CyanogenMod CM12 Nightly):

  1. Users are advised to update their third party addons to ensure compatibility
  2. The CM in recovery will ignore and remove incompatible applications from your system partition (these are usually non-CM apps that users have opted to install). You must install a compatible app (or app pack) to regain that functionality
  3. You can flash CM12 nightlies directly from CM11 M12 or CM 11 nightlies (no need to wipe), provided you read and followed items 1 and 2
  4. Once on CM12 nightlies, you cannot downgrade back to CM11 without wiping – if you are thinking of just exploring the release, then take a backup of your existing installation if you want to go back to it.
  5. Users must install Lollipop OS compatible recovery before installing the new CM12 custom ROM.
  6. Make sure the device is rooted before going forward for custom ROM installation
  7. This new CyanogenMod CM12 Android 5.0.2 Lollipop firmware has to be installed on the HTC One M7 model only ; if tried on other devices, it might get bricked [To check your device model: Go to Settings >> About phone >> model number]
  8. Installation of custom ROM requires clearing of memory in the smartphone, so make sure to back all the data by installing Clockwork Mod (CWM) Recovery/ TWRP in the smartphone.
  9. Users make sure you have installed USB drivers on the PC, or else your smartphone (HTC One M7) will not be recognized by the computer.
  10. Make sure your device has more than 80% battery, or else there is a chance of smartphone getting temporarily bricked if the installation process is interrupted midway.

[Disclaimer: This procedure is very technical and should be performed by a person with sound knowledge of rooting (or manual software installation) Android devices. If the step-by-step installation process is not followed properly, there are chances of the smartphone getting bricked or being permanently irreparable. International Business Times, India Edition cannot be held responsible for any damage or claims from readers if the procedure does not yield the required results or if the smartphone is bricked. Hence, users are advised to proceed with caution.]

Tutorial: Step-by-step Installation Guide for CyanogenMod [official] Android 5.0.2 Lollipop CM12 custom ROM on HTC One M7 (GSM) model-

Step 1: Download CyanogenMod [official] Android 5.0.2 Lollipop CM12 custom ROM build (HERE) and Google Apps (HERE) in to your PC.

[Note: OS build release-date - 15/01/2015]

Step 2: Connect HTC One M7 to PC via USB cord.

[Note: Before plugging the phone to the computer, be sure that you have installed USB driver software, if not, click HERE to download the firmware]

Step 3: Then, place Android 5.0.2 Lollipop zip file and Google Apps files into the phone's SD card memory. [Note: Users are advised to paste the .zip file in SD card root, not in any other folder.]

[Note: Before installing the custom software, be sure that the device must have been rooted and has installed ClockworkMod Recovery tool.]

Step 4: Later, place boot.img file in to the android-sdk-windowsplatform-tools directory

Step 5: Now, turn off the device and disconnect from the PC.

Step 6: Perform the regular Bootloader mode sortie, by press holding 'Volume (Down)' and 'Power' buttons.

Step 7: After entering the Bootloader mode (on the phone), go to android-sdk-windowsplatform-tools directory (on the PC) and open Command prompt, then type in: 'fastboot flash boot boot.img' and press enter.

(To enter Command prompt: Shift + right-click >> open Command Prompt)

Step 8: Then, type - 'fastboot reboot' and press enter. Then, follow instructions displayed on the screen. Select BOOTLOADER option to enter Recovery Mode.

Step 9: After entering the Recovery mode, clear the phone memory, by choosing 'wipe data/factory reset' [Note: use Volume keys to navigate and power button to select options, while operating under Recovery Mode]

Step 10: Now, clear the cache memory by selecting 'wipe cache partition'.

Step 11: Then to go back to ClockworkMod recovery, and select 'advanced' and tap 'wipe dalvik cache' [Note: This step is optional, but many recommend this procedure so that user will not face boot loops or any other errors in the middle of custom ROM installation]

Step 12: Again come back to main recovery screen and then tap 'install zip from SD card'

Step 13: Then tap 'choose zip from sdcard' and go to Android 5.0.2 Lollipop ROM .zip file in SD card and enter the installation process. Repeat the same procedure for Google Apps [Note: use Volume keys to navigate and power button to select options]

Step 14: Once done with the installation process, navigate to '+++++Go Back+++++' and re-start the device by opting 'reboot system now' seen in the recovery menu.

Now, your device (HTC One M7) will take a few minutes (only for the first time) to complete the booting process.

Head to Settings >> select About phone to confirm the installation of Android 5.0.2 Lollipop custom ROM.

[Credits: CyanogenMod.Org]
